G80 Clevis Sling Hook With Latch

G80 Clevis Sling Hooks are a general purpose hook, suitable for most slinging applications.
Clevis Sling Hook fitted with sturdy spring loaded safety latch for added security in lifting. Clevis allows easy connection to Chain.



+86-532-8309-2988
Products Introduction
Product Features:
• Alloy steel, quenched and tempered.
• Painted finish.
• Suitable for use with Grade 8 Chains.
• Clevis fitting enables direct connection to chain.
G80 CLEVIS SLING HOOK WITH LATCH
Specifications
G80 CLEVIS SLING HOOK WITH LATCH
SIZE WEIGHT WLL B.L DIMENSIONS(MM)
MM KG/PC TON TON A B E D H L
6 0.32 1.12 4.48 8 32 26 35 23 76
7/8 0.48 2.0 8 9.5 37 29 37 32.5 85.5
10 0.95 3.15 12.6 13 49 39 46 35 104
13 1.8 5.3 21.2 16.5 56.5 47 56 42.5 128
16 3.4 8 32 21.5 70.5 55 60 54 150
20 6 12.5 50 24 77 61 79 58 180
22 10.4 15 60 27 91 72 101 62 213
26 14.5 21.2 84.8 30 117 85 115 75 250
32 27 31.5 126 35 150 106 140 88 317
